Unique & Exclusive Technology

MySeat's proprietary hardware and software stack is purpose-built for workplace optimization, delivering unparalleled accuracy with minimal maintenance.

Principle of Detection

How MySeat Touch Sensors precisely measure occupancy using accelerometer technology

Accelerometer-Based Micromovement Detection

1

MySeat sensors detect the subtle micromovements that occur when a person touchs a surface.

2

Each sensor is equipped with a high-precision 3 axis accelerometer that measures micro-vibrations (10E-6)x g and processes the 150 samples per second to determin if the a strcture is used

3

The system distinguishes between object presence (like placing an object) and actual human presence using refined algorithms.

4

Within 4-10 seconds, the system accurately detects occupancy status changes with 99.8% accuracy.

Unlike infrared or radar-based systems, MySeat sensors don't require line-of-sight or constant emission of signals, making them more reliable, efficient, and privacy-conscious.

MySeat accelerometer detection principle diagram showing how sensors detect occupancy in a 4-person collaborative booth

Accelerometer-Based Sensing

Unlike camera or infrared solutions, our accelerometer technology detects actual presence while preserving privacy, with 99.8% accuracy.

10-Year Battery Life

Industry-leading power efficiency means our sensors run for up to 10 years on a single battery, dramatically reducing maintenance costs.

100% Wireless Installation

Set up in seconds without wiring, network configuration, or IT involvement. Each sensor works independently and securely.

Advanced Data Analytics

Our proprietary algorithms turn raw data into actionable insights, identifying patterns and opportunities other systems miss.

Canadian-Made Quality

Designed and manufactured in Quebec, our sensors meet the highest standards of reliability and performance in any environment.

Ultra-low Maintenance Design

Install once and forget. No calibration, no firmware updates, and no adjustments needed thanks to our industrial-grade components.

MySeat Touch Sensor vs Other Sensors

Not all occupancy sensors are created equal. See how the MySeat Touch Sensor outperforms other solutions with its unmatched features.

Feature
MySeat LogoMySeat Touch Sensor
IR
Infrared Sensors
RD
Radar Sensors

Installation

Where sensors are installed

Peel-and-Stick

Embedded into office furniture - Easy installation & removal

Close to the user's body

Requires proximity to the user

On top of the Desk

Requires precise positioning and power

Battery Life

How long before batteries need replacement

Up to 10 years

Long-lasting 3.6V Lithium performance

6-8 months

Frequent replacements

Wired only

Requires permanent power

Technology

Sensor type and methodology

Accelerometer-Based

Detects micromovement with 99.8% accuracy

Infrared detection

Heat-based detection only

Radar waves

Requires specific detection zones

Maintenance

Ongoing upkeep requirements

Ultra-Low maintenance

Thousands of connected data points managed by our team of experts

Heavy maintenance

Battery changes, lens cleaning

Frequent repositioning

Sensors may shift due to normal desk utilization

Environmental Resilience

Performance in varying conditions

Industrial grade

Protected against any type of alteration, unsesitive to temperature variations, does not require proximity to user. Operating temp: -40°C to +85°C,

Temperature sensitive

Affected by heat, sunlight, and obstacles

Signal interference

Sensor cross-talk when used in proximity to each other. Can also be affected by obstacles

Communication

How data is transmitted

2.4GHz IEEE802.15.4 + 5G Cellular

100% independant from the client network

High offline rate

Variable performance depending on the battery level

Wired or Wifi Dependant

Limited integration options

Wave Emissions

Electromagnetic radiation emitted

Ultra-low emissions

40,000× less than WiFi, only on state change, does not require proximity to the user's body

Moderate

Placed less than 10 cm from the users body for leg detection

High

Constant radar wave emission

MySeat's Sensor Specification

Our proprietary hardware-software solution is designed to measure occupancy rates with precision at the individual desk and room level.

Sensor Hardware Specifications

  • Microcontroller: 32-bit RISC CPU, IEEE802.15.4 and LoraWAN compatible
  • Memory: 128kB ROM, 128kB RAM, 4Mbit serial flash
  • Sampling frequency: 50 samples per second (50Hz) x 3-axis
  • Battery: 3.6V Lithium (replaceable), 2200mAh
  • Wireless Range: Up to 400 meters indoor (environment dependent)
  • Dimensions: 49mm x 39mm x 28mm

Platform & Data Capabilities

  • Real-Time Data: Updates within 3 to 10 seconds of state change
  • Dashboard: Live occupancy maps and historical analytics
  • Connectivity: Cloud-based with optional Ethernet/GPRS/3G gateway
  • Security: Encrypted data transmission and storage
  • Device Intelligence: Built-in algorithms handle exceptions, such us connectivity interruption
  • API: REST with custom Endpoints

Patended apparatus and system for detecting equipment occupancy under patent numbers CA2972898C, US10373448B2, WO2016108072A1, EP3241192B1 SG11201705384RA.

Designed and manufactured in Quebec, Canada

Licensing Opportunities for Manufacturers & Integrators

We offer flexible licensing options for our proprietary accelerometer-based sensing technology, allowing manufacturers and system integrators to incorporate our advanced detection capabilities into their products.

Technology and patent licensing for hardware manufacturers

Integration support for workplace management systems

Co-branded solutions with established partners

Custom detection algorithm development
